Description
| Rated cross-section |
Number of indiv. Wires Guided value |
Diameter of indiv. Wires max. |
Diameter of cond. Max. |
Resistance at 20°C max. |
Wall thickness | Core diameter |
Wall Thickness | External diameter |
Weight approx. |
|
| mm2 | mm | mm | mQ/m | mm | mm | mm | Min. mm | Max. mm | ||
| 0.50(+0.50) | 19 | 0.19 | 1.00 | 37.1 | 0.30 | 1.50 | 0.40 | 3.1 | 3.5 | – |
| 2×0.501+0.50) | 19 | 0.19 | 1.00 | 37.1 | 0.30 | 1.50 | 0.60 | 4.3 | 4.7 | – |
| 3×0.50(+0.50) | 19 | 0.19 | 1.00 | 37.1 | 0.30 | 1.50 | 0.60 | 4.5 | 4.9 | – |
| 4×0.50|+0.50) | 19 | 0.19 | 1.00 | 37.1 | 0.30 | 1.50 | 0.60 | 4.9 | 5.3 | – |
| 6×0.501+0.50) | 19 | 0.19 | 1.00 | 37.1 | 0.30 | 1.50 | 0.60 | 6.0 | 6.4 | – |
| ‘0.351+0.35) | 7 | 0.26 | 0.80 | 54.5 | 0.25 | 1.25 | 0.50 | 2.9 | 3.3 | – |
| *2×0.351+0.35) | 7 | 0.26 | 0.80 | 54.5 | 0.25 | 1.25 | 0.50 | 3.4 | 3.8 | – |
| *3×0.351+0.35) | 7 | 0.26 | 0.80 | 54.5 | 0.25 | 1.25 | 0.50 | 3.7 | 4.1 | – |
