Description
| Rated cross-section |
Number of indiv. Wires Guided value |
Diameter of indiv. Wires max. |
Diameter of cond. Max. |
Resistance at 20°C max. |
Wall thickness | Core diameter |
Wall Thickness | External diameter |
Weight approx. |
|
| mm2 | mm | mm | mQ/m. | nom. mm |
nom. mm |
nom. mm |
min. mm |
max. mm |
kg/1000 m | |
| 0.50 | 16 | 0.21 | 1.10 | 37.1 | 0.60 | 2.1 | 0.50 | 3.2 | 3.6 | 21 |
| 0.75 | 24 | 0.21D | 1.30 | 24.7 | 0.60 | 2.3 | 0.50 | 3.5 | 3.9 | 27 |
| 1.00 | 32 | 0.21 | 1.50 | 18.5 | 0.60 | 2.4 | 0.40 | 3.5 | 3.9 | 3, |
| *2×0.50 | 19 | 0.19 | 1.00 | 37.1 | 0.30 | 1.5 | 0.80 | 4.8 | 5.2 | 33 |
| 3×0.50 | 19 | 0.19 | 1.00 | 37.1 | 0.30 | 1.5 | 0.80 | 5.1 | 5.5 | 36 |
| 2×0.75 | ,9 | 0.23 | 1.20 | 24.7 | 0.30 | 1.8 | 0.80 | 5.2 | 5.6 | 38 |
| 3×0.75 | 19 | 0.23 | 1.20 | 24.7 | 0.30 | 1.8 | 0.80 | 5.5 | 5.9 | 46 |
| 4×0.75 | 19 | 0.23 | 1.20 | 24.7 | 0.30 | 1.8 | 0.80 | 6.0 | 6.4 | 61 |
| 6×0.75 | 19 | 0.23 | 1.20 | 24.7 | 0.30 | 1.8 | 0.90 | 7.2 | 7.6 | 82 |
| *2×1.00 | 19 | 0.26 | 1.35 | 18.5 | 0.30 | 2.0 | 0.80 | 5.6 | 6.0 | 46 |
