Description
| Number of wires x Rated Cross-section |
Number of indiv. Wires Guided value |
Diameter of indiv. Wires max. |
Diameter of cond. Max. |
Resistance at 20°C max. |
Insulation wall thickness Rated Value |
Sheath thickness Guide value |
External measurement Width |
External measurement Height |
Weight approx. |
||
| mm2 | mm | mm | mΩ/m | nom. Mm |
nom. Mm |
min. Mm |
max. Mm |
min. Mm |
max. Mm |
Kg/1000m | |
| 2×0.50 | 16 | 0,21 | 1,10 | 37,1 | 0,6 | 0,5 | 3,0 | 3,3 | 5 | 5,4 | 37 |
| 2×0.75 | 24 | 0,21 | 1,30 | 24,7 | 0,6 | 0,5 | 3,2 | 3,5 | 5,4 | 5,8 | 44 |
| 2×1.00 | 32 | 0,21 | 1,50 | 18,5 | 0,6 | 0,5 | 3,4 | 3,7 | 5,8 | 6,2 | 52 |
| 2×1.50 | 30 | 0,26 | 1,80 | 12,7 | 0,6 | 0,5 | 3,7 | 4,0 | 6,4 | 6,8 | 65 |
| 2×2.50 | 50 | 0,26 | 2,20 | 7,6 | 0,7 | 0,5 | 4,3 | 4,7 | 7,6 | 8,4 | 99 |
