Description
| Rated cross-section |
Number of indiv. Wires Guided value |
Diameter of indiv. Wires max. |
Diameter of cond. Max. |
Resistance at 20°C max. |
Insulation wall thickness Rated Value |
Sheath thickness Guide value |
External diameter |
Weight approx. |
||
| mΩ/m | ||||||||||
| mm2 | mm | mm | bare | tin piated | mm | mm | min. Mm |
max. Mm |
kg / 1000m | |
| 2 x 0.50 | 16 | 0.21 | 1.1 | 37.1 | 38.2 | 0.6 | 0.6 | 5.1 | 5.5 | 48 |
| 3 x 0.50 | 16 | 0.21 | 1.1 | 37.1 | 38.2 | 0.6 | 0.6 | 5.4 | 5.8 | 58 |
| 2 x 0.75 | 24 | 0.21 | 1.3 | 24.7 | 25.4 | 0.6 | 0.6 | 5.5 | 5.9 | 49 |
| 3 x 0.75 | 24 | 0.21 | 1.3 | 24.7 | 25.4 | 0.6 | 0.6 | 5.9 | 6.3 | 59 |
| 2 x 1.00 | 32 | 0.21 | 1.5 | 18.5 | 19.1 | 0.6 | 0.6 | 5.9 | 6.3 | 57 |
| 3 x 1.00 | 32 | 0.21 | 1.5 | 18.5 | 19.1 | 0.6 | 0.6 | 6.3 | 6.7 | 70 |
| 2 x 1.50 | 30 | 0.26 | 1.8 | 12.7 | 13.0 | 0.6 | 0.6 | 6.4 | 6.8 | 73 |
| 3 x 1.50 | 30 | 0.26 | 1.8 | 12.7 | 13.0 | 0.6 | 0.6 | 8.9 | 9.0 | 124 |
| 4×1.00 | 32 | 0.21 | 1.5 | 18.5 | 19.1 | 0.6 | 0.6 | 8.8 | 9.0 | 105 |
| 4×1.50 | 30 | 0.26 | 1.8 | 12.7 | 13.0 | 0.6 | 0.6 | 9.1 | 9.2 | 145 |
| 5 x 1.00 | 32 | 0.21 | 1.5 | 18.5 | 19.1 | 0.6 | 0.6 | 9.4 | 9.5 | 143 |
| 5 x 1.50 | 30 | 0.26 | 1.8 | 12.7 | 13.0 | 0.6 | 0.6 | 10.2 | 10.3 | 190 |
| 7 x 1.00 | 32 | 0.21 | 1.5 | 18.5 | 19.1 | 0.6 | 0.6 | 9.8 | 10.0 | 162 |
| 7x 1.50 | 30 | 0.26 | 1.8 | 12.7 | 13.0 | 0.6 | 0.6 | 10.2 | 10.9 | 228 |
